TYC Radiator Assembly

Manufacturer’s Warranty : Limited Lifetime for non-commercial use

Easy Return : We’re only happy if you’re happy. If you’re not entirely satisfied with your order, you may be entitled to a refund.

Fast Shipping : We ship fast so you can get on the road that much faster. Check out our Shipping Policy for more details.

$173.54 ~~$188.63~~ 8% Off

Product Description

TYC® 13510 Radiator

15-20 FD F150 3.5L V6 A/MT 1R PA RAD

OE-comparable core dimensions to achieve sufficent surface area for optimal cooling.

Rigorous and accelerated cycling tests to ensure product service quality and durability.

Individually leak-tested to ensure product has no leaks.

Toc Outlet Type	-	Tube fitting
Fin Count (every 4")	-	92
Core Thickness (in)	-	1.02
Inlet Diameter (in)	-	1.48
Find Wave Pitch	-	2.2
Outlet Connection Type	-	Quick connect (spring lock)
Fin Wave Height (in)	-	0.25
Toc Distance (in)	-	11.81
Tube Width X Height	-	26x2
Inlet Connection Type	-	Hose clamp
Top Header	-	1.79x18.83
Outlet Diameter (in)	-	1.52
Tube Count (every 4")	-	12
Total Fin Row Count	-	55
No. Of Rows	-	1
Engine Oil Cooler Included	-	No
Transmission Oil Cooler Included	-	Yes
Transmission Oil Cooler Type	-	Plate oil cooler
Core Material	-	Aluminum
Flow Configuration	-	Crossflow
Core Length (in)	-	34.65
Toc Inlet Diameter (in)	-	0.5
Toc Inlet Type	-	Tube fitting
Bottom Header	-	2.72x18.86
Core Height (in)	-	17.89
Total Tube Count	-	54
Toc Outlet Diameter (in)	-	0.5
Show All
