Description

LuK DMF Manu

Manufacturer’s Warranty : 12 months/12,000 miles

Easy Return : We’re only happy if you’re happy. If you’re not entirely satisfied with your order, you may be entitled to a refund.

Fast Shipping : We ship fast so you can get on the road that much faster. Check out our Shipping Policy for more details.

Place Your Order by 1:00 PM EST, It Will Be Ship Today!

$375.65 ~~$408.32~~ 8% Off

Only 1 left in stock - order soon.

SKU	LKDMF047
Brand	LUK®
Part Name	Clutch Flywheel
Part	# DMF047
UPC	# 00670774065736
Quantity Per Vehicle	1
Pack of	1
Condition	New

Fast Shipping

We ship fast so you can get on the road that much faster
100% Safety

Only secure payments

Product Description

LUK® DMF047 Clutch Flywheel

LuK: Don’t gamble – stay with the original LuK DMF! The LuK DMF prevents damages solid flywheels may cause. The LUK Dual Mass Flywheel (DMF) is individually fine-tuned for every type of car. The risks of using solid flywheels are numerous – from increased wear of engine mounts through gearbox failure to damaged crankshafts.

PRODUCT ATTRIBUTE & INFO

Torque Capacity DMFW (inch)	-	19.685
Torque Capacity DMFW (mm)	-	500
Crank Hole Dia. (inch)	-	0.4213
Crank Hole Dia. (mm)	-	10.7
Number of teeth, starter ring gear	-	115
Flywheel Thickness [mm] (inch)	-	1.7835
Flywheel Thickness [mm] (mm)	-	45.3
Dowel hole diameter (inch)	-	0.2874
Dowel hole diameter (mm)	-	7.3
Dowel Hole Pattern	-	5
Crank To Friction Surface (inch)	-	1.6575
Crank To Friction Surface (mm)	-	42.1
Ring Gear Major Dia. (inch)	-	11.4766
Ring Gear Major Dia. (mm)	-	291.505
Flywheel Friction Surface Inner diameter (inch)	-	6.2205
Flywheel Friction Surface Inner diameter (mm)	-	158
Ring Gear Thickness (inch)	-	0.3543
Ring Gear Thickness (mm)	-	9
Centering diameter / dowel hole (inch)	-	11.2598
Centering diameter / dowel hole (mm)	-	286
Cup depth, secondary flywheel (inch)	-	0.185
Cup depth, secondary flywheel (mm)	-	4.7
I.D. for Pilot (inch)	-	1.7795
I.D. for Pilot (mm)	-	45.2
Bolt hole PCD crankshaft (inch)	-	2.9134
Bolt hole PCD crankshaft (mm)	-	74
Ring Gear To Friction Surface (inch)	-	1.5984
Ring Gear To Friction Surface (mm)	-	40.6
Flywheel friction surface outer diameter (inch)	-	9.9213
Flywheel friction surface outer diameter (mm)	-	252
Ring Gear Number	-	L-01180-0050-00
Bolt Hole Pattern	-	18
Ring Gear Mounting O.D. (inch)	-	10.3543
Ring Gear Mounting O.D. (mm)	-	263
Bolt hole PCD clutch pres.plte (inch)	-	11.2598
Bolt hole PCD clutch pres.plte (mm)	-	286
Overall Casting O.D. (inch)	-	11.9291
Overall Casting O.D. (mm)	-	303
Show All
